Roland DG ECO-UV Inks, with the ink codes, capacities, colours and printer references listed in Roland’s Know Your Printer, Know Your Ink chart.
Part numbers, colours and capacities
EUV Ver2
| Part number |
Colour / fluid |
Capacity |
| EUV-CY |
Cyan (Cy) |
220cc |
| EUV-MG |
Magenta (Mg) |
220cc |
| EUV-YE |
Yellow (Ye) |
220cc |
| EUV-BK |
Black (Bk) |
220cc |
| EUV-WH |
White (Wh) |
220cc |
| EUV-GL |
Gloss (Gl) |
220cc |
EUV-Pr
Primer for EUV/EUV4.
| Part number |
Colour / fluid |
Capacity |
| EUV-PR |
Primer (Pr) |
220cc |
EUV Stretch
| Part number |
Colour / fluid |
Capacity |
| EUVSCY |
Cyan (Cy) |
220cc |
| EUVSMG |
Magenta (Mg) |
220cc |
| EUVSYE |
Yellow (Ye) |
220cc |
| EUVSBK |
Black (Bk) |
220cc |
| EUVSWH |
White (Wh) |
220cc |
EUV4
| Part number |
Colour / fluid |
Capacity |
| EUV4-CY |
Cyan (Cy) |
220cc |
| EUV4-MG |
Magenta (Mg) |
220cc |
| EUV4-YE |
Yellow (Ye) |
220cc |
| EUV4-BK |
Black (Bk) |
220cc |
| EUV4-WH |
White (Wh) |
220cc |
| EUV4-GL |
Gloss (Gl) |
220cc |
EUV4-5
| Part number |
Colour / fluid |
Capacity |
| EUV4-5CY |
Cyan (Cy) |
500cc |
| EUV4-5MG |
Magenta (Mg) |
500cc |
| EUV4-5YE |
Yellow (Ye) |
500cc |
| EUV4-5BK |
Black (Bk) |
500cc |
| EUV4-5GL |
Gloss (Gl) |
500cc |
EUV5-2
| Part number |
Colour / fluid |
Capacity |
| On enquiry |
Cyan (Cy) |
200cc |
| On enquiry |
Magenta (Mg) |
200cc |
| On enquiry |
Yellow (Ye) |
200cc |
| On enquiry |
Black (Bk) |
200cc |
| On enquiry |
Primer (Pr) |
200cc |
EUV5-5
| Part number |
Colour / fluid |
Capacity |
| EUV5-5CY |
Cyan (Cy) |
500cc |
| EUV5-5MG |
Magenta (Mg) |
500cc |
| EUV5-5YE |
Yellow (Ye) |
500cc |
| EUV5-5BK |
Black (Bk) |
500cc |
| EUV5-5GL |
Gloss (Gl) |
500cc |
| EUV5-5PR |
Primer (Pr) |
500cc |
| EUV5-5OR |
Orange (Or) |
500cc |
| EUV5-5RE |
Red (Re) |
500cc |
EUV5
| Part number |
Colour / fluid |
Capacity |
| EUV5-WH |
White (Wh) |
220cc |
EUV5P-7 *
| Part number |
Colour / fluid |
Capacity |
| EUV5P-7CY |
Cyan (Cy) |
750cc |
| EUV5P-7MG |
Magenta (Mg) |
750cc |
| EUV5P-7YE |
Yellow (Ye) |
750cc |
| EUV5P-7BK |
Black (Bk) |
750cc |
| EUV5P-7WH |
White (Wh) |
750cc |
| EUV5P-7GL |
Gloss (Gl) |
750cc |
| EUV5P-7PR |
Primer (Pr) |
750cc |
| EUV5P-7OR |
Orange (Or) |
750cc |
| EUV5P-7RE |
Red (Re) |
750cc |
EUV-A7 *
| Part number |
Colour / fluid |
Capacity |
| On enquiry |
Cyan (Cy) |
750cc |
| On enquiry |
Magenta (Mg) |
750cc |
| On enquiry |
Yellow (Ye) |
750cc |
| On enquiry |
Black (Bk) |
750cc |
| On enquiry |
White (Wh) |
750cc |
| On enquiry |
Gloss (Gl) |
750cc |
EUV-HP7 *
| Part number |
Colour / fluid |
Capacity |
| On enquiry |
Cyan (Cy) |
750cc |
| On enquiry |
Magenta (Mg) |
750cc |
| On enquiry |
Yellow (Ye) |
750cc |
| On enquiry |
Black (Bk) |
750cc |
| On enquiry |
White (Wh) |
750cc |
| On enquiry |
Gloss (Gl) |
750cc |
| On enquiry |
Primer (Pr) |
750cc |
EUV5-P10 *
| Part number |
Colour / fluid |
Capacity |
| On enquiry |
Cyan (Cy) |
1000cc |
| On enquiry |
Magenta (Mg) |
1000cc |
| On enquiry |
Yellow (Ye) |
1000cc |
| On enquiry |
Black (Bk) |
1000cc |
| On enquiry |
White (Wh) |
1000cc |
| On enquiry |
Gloss (Gl) |
1000cc |
| On enquiry |
Primer (Pr) |
1000cc |
| On enquiry |
Orange (Or) |
1000cc |
| On enquiry |
Red (Re) |
1000cc |
D-UA-5
| Part number |
Colour / fluid |
Capacity |
| D-UA-5CY |
Cyan (Cy) |
500cc |
| D-UA-5MG |
Magenta (Mg) |
500cc |
| D-UA-5YE |
Yellow (Ye) |
500cc |
| D-UA-5BK |
Black (Bk) |
500cc |
| D-UA-5GL |
Gloss (Gl) |
500cc |
D-UA
| Part number |
Colour / fluid |
Capacity |
| D-UA-WH |
White (Wh) |
220cc |
D-UAP-7 *
| Part number |
Colour / fluid |
Capacity |
| D-UAP-7CY |
Cyan (Cy) |
750cc |
| D-UAP-7MG |
Magenta (Mg) |
750cc |
| D-UAP-7YE |
Yellow (Ye) |
750cc |
| D-UAP-7BK |
Black (Bk) |
750cc |
| D-UAP-7GL |
Gloss (Gl) |
750cc |
| D-UAP-7WH |
White (Wh) |
750cc |
D-UAP2P10 *
| Part number |
Colour / fluid |
Capacity |
| On enquiry |
Cyan (Cy) |
1000cc |
| On enquiry |
Magenta (Mg) |
1000cc |
| On enquiry |
Yellow (Ye) |
1000cc |
| On enquiry |
Black (Bk) |
1000cc |
| On enquiry |
Gloss (Gl) |
1000cc |
| On enquiry |
White (Wh) |
1000cc |
US
| Part number |
Colour / fluid |
Capacity |
| US-CY |
Cyan (Cy) |
1000cc |
| US-MG |
Magenta (Mg) |
1000cc |
| US-YE |
Yellow (Ye) |
1000cc |
| US-BK |
Black (Bk) |
1000cc |
| US-WH |
White (Wh) |
1000cc |
| US-GL |
Gloss (Gl) |
1000cc |
| US-PR |
Primer (Pr) |
1000cc |
Contact us for the part number of entries marked On enquiry.
Printer references
- LEC-300/330/540: EUV 2/4/4-5/S
- LEJ-640: EUV 2/4/4-5/S
- LEF-12/12i/20/200/2-200: EUV 2/4
- LEF-300/2-300: EUV 4/4-5
- LEC2-300: EUV 4/4-5
- LEC2-640/330: EUV 5-5/S
- MG-640/300: EUV 5-5/S
- CO-640/300i: EUV 5-5/S
- BD-8/BD-12: EUV 5-2
- LO-300/640: EUV 5P-7/A7/HP7
- LG-640/540/300: EUV 5P-7/A7/HP7
- MO-240/180: EUV 5P-7/A7/HP7
- IO-300: EUV 5P-7/A7/HP7
- RC-300/c: EUV 5P-7/A7/HP7
- UG-641: D-UA-5
- UG-642: D-UAP-7
- MG2-640/300: EUV 5P-7/D-UAP2
- IU-1000F: UV-US
Cleaning references
| Cleaning item |
Reference |
| US Cleaning Solutions |
US-CL |
| Cleaning Kit SLCL |
SP-RL-6701409310 |
| Cleaning Cartridge |
SLCL |
| Cleaning Cartridge |
ESL5P-CL * |
Compatibility labels are transcribed as printed; the chart uses different shorthand in some printer labels and part-number rows. Asterisks are retained from the source, which gives no explicit written legend. These formulations are not presented as universally interchangeable.
Select the ink formulation and colour for the specific printer configuration.
